Article number: 00 835 28 99

Shower panel LINUS Trend DP-SC-T-D-H

Discontinued
Made from strong stainless steel with a high-quality, brushed finish. Manual actuation with automatic closing. Single-person assembly for easy installation and servicing. Suitable for connections from rear or for exposed connections from above.
Remember Compare Redirect Datasheet
Find contact person on site
Scope of supply Technical data Related items BIM/CAD

Scope of delivery

  • Self-closing exposed shower panel
    • Operating button for thermostat with push sleeve, temperature setting unlockable/lockable at 38 °C
    • SC self-closing button
    • Self-closing cartridge SC
    • ThermoProtect thermostat, conform to EN 1111, anti-scalding protection if cold water supply fails
  • COMFORT shower head 13°, vandal-resistant, with soft stream and anti-limescale burls
  • Hand shower, 3-way adjustable and connection hose
  • Connection accessories with isolating valve(s), backflow preventer (EN 1717: EB-type) and pre-filter
  • Fastening material for wall installation

Delivery data

  • Weight: 10,20 kg/Piece
  • Packing unit: 1

Technical data

  • Running time: 5 - 30 s
  • Flow at 3 bar: 9 l/min
  • Flow pressure: 1.0 - 5.0 bar
  • Max. operating temperature: 70 °C temporarily
  • Material: Actuation Brass; Housing Stainless steel
  • Surface: Outlet Chrome; Actuation Chrome; Housing Brushed stainless steel
  • Dimensions: w 220 mm x h 1263 mm x d 70 mm
  • length shower hose: 1500 mm
  • Connection: 2x DN 15 G 1/2 AG
  • Certificates: Belgaqua
Recommended associated articles
Soap tray LINUS Trend
Article no: 00 836 28 99
Hint
  • Discontinued article, as long as stocks last
