Article number: 02 169 06 99

Electronic wash basin tap MODUS Trend E

HD-K - high-pressure cold water/pre-mixed water
Infrared sensor-controlled. Mains operation.
Remember Compare Redirect Datasheet
Find contact person on site
Scope of supply Technical data Related items BIM/CAD

Scope of delivery

  • Infrared sensor single-hole tap
    • Infrared sensor electronics, programmable
    • 6 V solenoid valve with pre-filter
    • Flow regulator
    • Connection cable, 200 mm, with 2-pin plug, protection class IP65
    • Flexible connection hose, G 3/8 IG x 450 mm, with pre-filter
  • Transformer plug 6 VDC, 100-240 VAC, 50-60 Hz
  • Fastening material for wash basin installation

Delivery data

  • Weight: 1,57 kg/Piece
  • Packing unit: 1

Technical data

  • Setting options via short range reflex
    • Sensor range area (approx. 2-17 cm)
    • Cleaning stop (off/120 s)
  • Energy saving mode: Automatic energy saving mode
  • Flow: max. 1 gpm ≈ 3,8 l/min
  • Flow pressure: 0.5 - 5.0 bar
  • Max. Resting pressure: 8 bar
  • Max. operating temperature: 70 °C (temporarily, e.g. for thermal disinfection)
  • Material: Housing Brass, conform to German drinking water regulations
  • Surface: Chrome
  • Connection: G 3/8 IG
  • Certificates: P-IX 29853/IO, WRAS applied
  • Noise class: I
  • Flow class: O
Recommended associated articles
Angle valve with regulating function COMFORT with filter
Article no: 05 430 06 99
Flow regulator set LEED 1.3 l
Article no: 28 931 06 99
Downloads

Installation instructions

MODUS Trend E

Flyer / Brochure

Contact-free wash basin tap MODUS Trend E. Hygiene at an attractive price.

Brochure

Washbasin taps.
